Wall Hung Toilet

A wall hung toilet is fixed to the wall with the bowl clear of the floor, and its outlet leaves through the wall instead of the floor. This collection holds 66 wall hung toilets: 64 wall-hung bowls and 2 wall-hung smart toilets. Flushing styles listed across the range include dual jet on 17 models, swirl on 16, rimless on 14 and washdown on 10. The printed P-trap height is 180 mm on 50 models, with others listing 135, 150, 170, 175 or 185 mm. Body lengths run from 470 to 606 mm and heights from 300 to 405 mm. White is listed on 63 models and black on 14, with gray, beige, gold, green and other colors on selected models. Hotel, apartment and commercial washroom projects can mix compact and longer bowls in one order, with outlet height and color confirmed per model.

Service
OEM / ODM · free mold from 300 pcs
MOQ
20 ft / 40 ft containersBelow 1 container: your own China forwarder required.
Lead time
30–45 days after sample

Concealed cisterns & flush plates

Choose a frame and plate for your wall-hung toilet project. We confirm the bowl, frame, wall depth and flushing system before quoting a matched set.

9 frame options
SN5101 full-frame concealed cistern original supplier specification sheet SN5101
SN5103 full-frame concealed cistern original supplier specification sheet SN5103
SN5108 full-frame concealed cistern original supplier specification sheet SN5108
SN03 full-frame concealed cistern original supplier specification sheet SN03
SN06 full-frame concealed cistern original supplier specification sheet SN06
SN07 full-frame concealed cistern original supplier specification sheet SN07
SN99BL full-frame concealed cistern original supplier specification sheet SN99BL
SN99DL full-frame concealed cistern original supplier specification sheet SN99DL
SN99J full-frame concealed cistern original supplier specification sheet SN99J

Scroll to compare · Select an image for its original specification sheet. Compatibility is confirmed by model; these systems are not universal.

Flush plates · Square / Oval / Rectangular / Round
Original concealed-cistern flush plate sheet showing Square, Oval, Rectangular and Round shapes Flush plate options

View the original plate range, then confirm the selected plate with the cistern model and activation system.

Plate shapes and finishes are subject to the matched configuration.

Separate option · SN5108 Half Frame for floor-standing or squat toilets
SN5108 half-frame original sheet showing separate floor-standing toilet and squat toilet configurations SN5108 · Half Frame

This half-frame sheet shows separate configurations for a floor-standing toilet or a squat toilet.

It is different from the full-frame SN5108 above. Confirm the required installation and pipe arrangement before ordering.

66 products

Send a spec. Get a real quote in 1 business day.

B2B only. Personal follow-up from SANIKB. A SANIKB engineer reads your brief and replies with feasibility, MOQ, lead-time and an itemised price — within 1 business day.

We send quotes within 1 business day after receiving the necessary product, quantity and destination details.

One itemised quote — not five
Feasibility & certification checked per market
Have a spec file? Attach it to your inquiry below.
— Project brief B2B only
Please enter your first name.
Please enter your company name.
Please enter a valid email.
Please enter your phone number.

Wholesale · 20 ft / 40 ft · Mix available

Drag & drop or browse PDF / IMG / XLS · 4MB ×3
    Engineer reply within 1 business day

    Factory documentation

    Certification scope depends on the selected model and destination market. Request model-specific documents with your quotation.

    IAPMO cUPC certificate
    ISO 9001 quality management certificate
    WRAS approved product certificate
    IAPMO certificate of listing
    UDEM CE technical inspection certificate

    Carrier first, catalog second

    Wall hung toilet planning: the carrier and outlet height come before styling

    A wall mounted toilet connects through the wall, so the printed P-trap height has to match the drain stub set behind the finished wall. Across all 66 models the height is 180 mm on 50 of them; examples of each other height are listed below.

    SANIKB LJ-E09 Wall-Hung Toilet product photo
    P-trap 180 mm
    50 of 66 models, including FT-805, FT-976, TC-7402 and TC-7107B
    P-trap 185 mm
    LJ-E06 (rimless), LJ-A03 (washdown)
    P-trap 175 mm
    LJ-A15 (rimless)
    P-trap 170 mm
    LJ-E09S and LJ-A13 (rimless), LJ-A07 (washdown)
    P-trap 150 mm
    LJ-E07 (rimless), LJ-A06 (washdown)
    P-trap 135 mm
    the 2 wall-hung smart toilets
    Outlet not printed
    FT-809 and FT-501R/510T: request the drawing before ordering

    If one building already has drain stubs set at a single height, filter to that figure first and choose flush and finish only from what remains.

    Wall hung versus floor mounted

    Wall mounted toilet or floor mounted toilet: what changes on site

    A wall hung toilet and a floor mounted toilet can look similar from the front. The difference is how each one connects to the building, and that decides the rough-in work.

    Support
    Wall hung: Bowl is fixed to the wall and sits clear of the floor. Floor mounted: Bowl rests on the bathroom floor.
    Waste pipe
    Wall hung: Leaves through the wall. Floor mounted: Leaves through the floor.
    Tank
    Wall hung: Tank usually concealed in the wall. Floor mounted: Visible tank or a back-to-wall body.
    Cleaning
    Wall hung: Open floor beneath makes cleaning easier. Floor mounted: Base and trap meet the floor.
    Rough-in work
    Wall hung: Needs a wall structure that carries the load. Floor mounted: Uses the existing floor drain.

    For a renovation in an existing bathroom, a floor mounted toilet is usually the quicker swap. For new builds and full refits, the wall hung toilet clears the floor beneath the bowl.

    Behind the finished wall

    In-wall carrier system and concealed tank: what to plan first

    A wall hung toilet bowl is only one part of the installation. The in-wall carrier and the concealed tank sit behind the finished wall, so they have to be settled before the wall is closed.

    1. Choose the in-wall carrier

      The wall carrier is a frame that holds the bowl and, in most layouts, an in-wall tank. Choose it with the bowl code in hand, and check the carrier frame against the mounting points shown on the bowl spec sheet.

    2. Check the wall structure

      Wall studs or a false wall must be able to support the carrier system. Confirm the wall structure with your builder or engineer, and check local building codes for the project.

    3. Fix the waste and water supply

      Set the waste pipe and the water supply to the outlet height printed for the bowl. A mismatch of even a small amount is hard to correct once the wall is tiled.

    4. Pick the flush plate

      The flush actuator plate sits on the finished wall and operates the in-wall tank. Decide the plate style together with the carrier.

    5. Add the seat and mounting hardware

      Check the toilet seat and mounting hardware against the bowl model before you order.

    Series codes decoded

    How the FT, LJ-E, LJ-A and TC families differ

    The bands below come from the FT, LJ-E, LJ-A and TC models featured on this page, and they overlap, so the prefix alone does not fix a size (millimeters, length × height).

    SANIKB LJ-A08 23 inch wall hung toilet 180mm p trap
    470–540
    FT lengths; dual jet or swirl where listed, heights 310 to 350
    485–535
    LJ-E lengths; all rimless, heights 340 to 370
    500–595
    LJ-A lengths; rimless or washdown, heights 350 to 375
    490–520
    TC lengths; Marble, Black and Gray glazes

    Among the featured models, the LJ-A08 washdown is the longest at 595 × 390 × 375 mm and the FT-543 dual jet the shortest at 470 × 360 × 340 mm. Across all 66 models, lengths run from 470 to 606 mm.

    One bowl per niche

    Eight wall hung toilet bowls side by side

    One or two models from each family, covering all four flush styles, the 180 mm and 150 mm outlets, and white, two-tone and colored glazes. Sizes are length × width × height in millimeters from each spec sheet.

    Swipe to compare all specifications

    ModelFlushP-trapSize (mm)FinishCE tag
    Shortest bodyFT-543Dual jet180 mm470 × 360 × 340White—
    Low swirl bodyFT-805Swirl180 mm490 × 360 × 310WhiteCE
    Two-finish dual jetFT-705Dual jet180 mm490 × 360 × 310White / BlackCE
    12-finish optionLJ-E03Rimless180 mm505 × 345 × 36512 finishes—
    150 mm outletLJ-E07Rimless150 mm535 × 360 × 340White—
    Rimless LJ-ALJ-A09HRimless180 mm550 × 355 × 365White / Matt Black—
    595 mm bodyLJ-A08Washdown180 mm595 × 390 × 375White—
    Colored glazeTC-7107BRimless180 mm520 × 360 × 360BlackCE

    A CE tag appears on TC-7107B, TC-7006G and ten FT models from FT-705 to FT-976; check the tag on each line before quoting into a CE market.

    Near-identical twins

    Close codes that are easy to confuse

    Several codes print the same or nearly the same dimensions and differ in suffix, flush style, outlet or finish list. Name the full code on every order line.

    SANIKB LJ-E09S hanging toiletLJ-E09 vs LJ-E09SBoth are 485 × 365 × 365 mm rimless bowls. LJ-E09 prints a 180 mm P-trap and lists 9 finishes; LJ-E09S prints 170 mm and lists white.SANIKB LJ-A09E 550mm washdown wall hung toiletLJ-A09, LJ-A09H, LJ-A09EThree 550 mm bodies at 180 mm: LJ-A09 (550 × 355 × 365 mm) is washdown in three finishes, LJ-A09H shares that size as a rimless bowl in white or matt black, and LJ-A09E is a white washdown at 550 × 365 × 370 mm.SANIKB FT-976 ft-976 swirl flush wall hung toiletFT-976, FT-876, FT176-BF-2All three print 520 × 360 × 310 mm and a 180 mm outlet. FT-976 and FT-876 are swirl with a CE tag; FT176-BF-2 is dual jet without one.SANIKB FT-806C ft-806c swirl flush wall hung toiletFT-806 vs FT-806C, FT-805 vs FT-805CEach pair prints the same size, swirl flush and outlet. Ask which detail the C suffix marks before you mix the two codes in one order.SANIKB FT-524-BF wall mounted floating toiletFT-524 vs FT-524-BFSame 540 × 360 × 350 mm dual jet body and 180 mm outlet; the BF suffix also appears on FT-824BF, so confirm what it changes on the drawing.

    Glaze options by model

    Which bodies leave white behind

    SANIKB TC-7107B Wall-Hung Toilet product photo

    White is listed on 63 of the 66 models, so a color program narrows the shortlist fast. Black is listed on 14; among them are matt black alongside white on LJ-E08, LJ-A09H, LJ-A06 and LJ-A03; glossy white, matt white and matt black on LJ-A15, LJ-A13, LJ-A12 and LJ-A09; white or black on FT-705; black within the multi-finish LJ-E09 and LJ-E03; and a black-only bowl, TC-7107B.

    For more than two colors, look at two rimless LJ-E models. LJ-E09 lists 9 finishes, including beige, gold, green, gray and orange, while LJ-E03 lists 12 finishes, including gold, green and silver. TC-7006G is a gray glaze and TC-7402 a marble glaze, both at 180 mm.

    FT-501R/510T is the decor option: a 510 × 345 × 310 mm white body offered in 15 decor designs. Its flush and outlet are not printed, so request the drawing along with the design references.

    Quote-ready in one email

    What to send when you request a quote

    Include these five items in a wall mounted toilet inquiry so each quotation line can be tied to one model, outlet height and finish.

    1. Model code with its suffix

      Write LJ-E09S or FT-806C in full; close codes can share a size, so the suffix identifies the exact model.

    2. Outlet height per building

      State the P-trap height your drain stubs are set for, and flag any building that differs, so each line is matched to a model that prints that height.

    3. Finish and quantity per line

      List glaze and quantity separately for each model. Pricing is quoted per order, and MOQ is set per model.

    4. Marking and branding

      Say if the destination market needs CE marking, and whether you need private label or packaging changes through our OEM program at /pages/oem-odm-service.

    5. Drawings for sign-off

      Ask for the spec sheet of each model so your plumber can check the outlet before walls are closed. Written replies come within 12 business hours.

    Project fit

    Small bathroom, hotel or multifamily: where a wall hung toilet fits

    A wall hung bowl clears the floor, which helps in tight rooms and in programs that repeat one bathroom many times.

    Small bathroom and tight spaces

    The floor beneath the bowl stays open for cleaning, and the range includes compact bodies from 470 mm.

    Hotels and commercial washrooms

    Hotel, apartment and commercial washroom projects can mix compact and longer bowls in one order, with outlet height and color confirmed per model.

    Existing bathroom upgrades

    Plan the wall depth first. If the wall cannot take a carrier, ask about a false wall or consider a floor mounted model instead.

    FAQs

    Which wall hung toilet models are in this collection?

    The collection holds 66 wall hung toilets: 64 wall-hung bowls and 2 wall-hung smart toilets. Body lengths run from 470 to 606 mm, widths from 340 to 390 mm and heights from 300 to 405 mm. Use the flushing and color filters to narrow the list, and see the rimless toilet collection for the rimless bowls across every body type.

    What P-trap heights do these wall hung toilets use?

    The printed P-trap height is 180 mm on 50 models. Other models list 135, 150, 170, 175 or 185 mm, so a single project may need more than one outlet height if the bowl changes. Match the printed height to the in-wall drain position on site, and confirm it against the drawing on each product page before walls are closed.

    Which flushing styles are listed for wall hung toilets?

    Flushing styles are listed per model: dual jet on 17 models, swirl on 16, rimless on 14 and washdown on 10. The flushing style is part of each model, not an option added later, so choose it together with the bowl shape. Mixed orders can carry different flushing styles for different room types, each named as a separate line on the quotation.

    What is the MOQ and lead time for wall hung toilets?

    MOQ, samples and lead time are quoted per model, because they depend on the model mix, finish, carton marking and destination. Send the wall hung toilet models, quantities and destination port in one inquiry, and the quotation states each figure line by line. Written replies are issued within 12 business hours, so a project schedule can be checked before the order is placed.

    Can wall hung toilets be supplied under our own brand?

    Private-label supply runs through the SANIKB OEM and ODM program: brand marking on the product, carton and inserts, with documents prepared model by model. Certification marks are listed per model (some models print CE or cUPC), so name the target market and the marks it requires, and the quotation lists which models fit. Several wall hung models can share one container, each with its own marking.

    How should a distributor choose between wall hung and back-to-wall toilets?

    Wall hung toilets keep the floor clear and rely on the wall for support, so they suit projects that plan the wall build-up from the start. Floor-standing back-to-wall toilets rest on the floor with a closed rear against the wall. Choose by wall construction first, then compare outlet height, body length and flushing style per model.
