Single-Ended Rectangular Drop-In Bathtub, 59 & 67 in
SANIKB D-8016Q is a rectangular acrylic drop-in bathtub with one sloped backrest end and a narrow flat flange that rests on the platform deck. It is made in two sizes: D-8016Q-150 at 1500 x 750 x 500 mm (59 x 29.5 x 19.7 in) and D-8016Q-170 at 1700 x 800 x 500 mm (67 x 31.5 x 19.7 in), so the longer shell is also 50 mm wider.
The flange has no tap holes; the faucet mounts on the surrounding deck or on the wall. D-8016Q is made in white and is cUPC certified. Distributors and contractors can compare it with other outlines in the SANIKB drop-in bathtub range; written quotes are returned within 12 business hours.
More in Drop-In Bathtubs
MOQ per model · one 40HQ container, quantity set by tub size
-
B8022Two-Person Drop-In Whirlpool Bathtub with Twin Headrests, 75 in75" × 55.1" × 29.1"Drop-in (deck or platform)
-
D-8028QCompact Round Drop-In Bathtub, 55 in Diameter55" × 55.1" × 19.3"Drop-in (deck or platform)
-
D-8061QRectangular Drop-In Tub with Wide Flat Flange, 59-71 in59" / 67" / 71" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8051QWide-Rim Double-Ended Drop-In Bathtub, 59 & 67 in59" / 67" × 30.7" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8026QDouble-Ended Rectangular Drop-In Bathtub, 71 in71" × 31.5" × 18.9"Drop-in (deck or platform)
-
D-8021QRectangular Drop-In Bathtub, 29.5 in Wide, 59 & 67 in59" / 67" × 29.5" × 19.3"Drop-in (deck or platform)
-
D-8017QDouble-Ended Drop-In Bathtub with Bowed Ends, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8013QRectangular Drop-In Acrylic Bathtub, Narrow Flat Flange, 59-67 in59" / 63" / 67" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8020QRounded Rectangle Double-Ended Drop-In Bathtub, 59-71 in59" / 67" / 71" × 29.5" × 19.3"Drop-in (deck or platform)
-
D-8062QNarrow Oval Drop-In Bathtub with Rolled Flange, 27.6 in Wide, 59 & 67 in59" / 67" × 27.6" × 18.5"Drop-in (deck or platform)
-
D-8022QStadium Drop-In Bathtub, White Gloss Acrylic, Narrow Flange, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8015QOval Drop-In Acrylic Bathtub, Narrow Rounded Flange, 59-67 in59" / 63" / 67" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8012QOval Drop-In Bathtub, Wide Flat Flange, 18.5 in High, 58-70 in58" / 61" / 65" / 70" × 31.3" / 31.5" / 31.7" × 18.5"Drop-in (deck or platform)
Tub sheet
Size and installation of D-8016Q
Every option below is a produced configuration with its own SKU. 2 sizes. Name the exact SKU on each purchase order line.
Order codes
| SKU | Size |
|---|---|
| D-8016Q-150 | 59" x 30" |
| D-8016Q-170 | 67" x 31" |
Mixed-configuration orders are accepted within one purchase order. Confirm the SKU, finish and size on the quotation before sample approval. Request the full configuration list.
Compare · 2 sizes
Size & spec comparison
| 59" x 30"D-8016Q-150 | 67" x 31"D-8016Q-170 | |
|---|---|---|
| Overall L×W×D | 59″ × 29.5″ × 19.7″ 1500 × 750 × 500 mm | 67″ × 31.5″ × 19.7″ 1700 × 800 × 500 mm |
Common specs above apply to every size; the table compares only what changes by size. Custom sizes available for OEM/ODM.
Send a spec. Get a real quote in 12 business hours.
Engineer-reviewed. cUPC · CE · ISO 9001 ready. 30–45 day lead time, FOB or CIF.
12 consecutive years at KBIS and IBS.
Standard on every shipment.
Shape & Backrest
Rectangular shell with one sloped backrest end
D-8016Q is a rectangular drop-in bathtub with a single-ended backrest. Once the shell is set in, the narrow flat flange is all that stays on view above the platform.
Single-ended bathing position
One end of the shell is shaped as the backrest, so the bather faces the opposite end. Decide which end of the platform takes the backrest before the faucet position is set out.
Narrow flat flange, no tap holes
The flange is kept narrow and flat and has no tap holes. The faucet mounts on the surrounding deck or on the wall, and the faucet and waste scope for D-8016Q is agreed at quotation.
Buyers who want a backrest at both ends can compare double-ended shells in the drop-in bathtub range.
Fit & Platform
Two lengths, 1500 mm and 1700 mm, both 500 mm high
D-8016Q-150 measures 59 x 29.5 x 19.7 inches (1500 x 750 x 500 mm). D-8016Q-170 measures 67 x 31.5 x 19.7 inches (1700 x 800 x 500 mm), so the longer size is also 50 mm wider.
- D-8016Q-150
- 59" x 29.5" x 19.7" (1500 x 750 x 500 mm)
- D-8016Q-170
- 67" x 31.5" x 19.7" (1700 x 800 x 500 mm)
- Installation
- Drop-in, flange rests on the platform deck
- Faucet Mounting
- Surrounding deck or wall; no tap holes in the flange
The two sizes differ in both length and width, so a platform framed for one will not take the other. Take the cut-out and drain position for D-8016Q-150 or D-8016Q-170 from the approved drawing for that size.
Frame the platform only once the approved drawing for the chosen D-8016Q size is in hand.
Construction & Finish
Acrylic shell in white
D-8016Q is made from pure acrylic sheet in white.
White
One color for both sizes
D-8016Q-150 and D-8016Q-170 are both made in white, so a project that mixes the two lengths keeps a single color across its bathrooms.
Gloss level is confirmed on the approval sample. If sheen matters to your specification, approve it on that sample before the order is confirmed.
Write the approved D-8016Q sample reference into the purchase order.
Compliance
cUPC certification for D-8016Q
Request documents against D-8016Q and name the size SKU you plan to order, D-8016Q-150 or D-8016Q-170.
D-8016Q is cUPC certified. Before the model goes into a submittal, ask for the certificate number and its validity so the paperwork matches your destination market.
Name the market and the documents you need when you send the D-8016Q inquiry; written replies are issued within 12 business hours.
Procurement
Ordering D-8016Q by size
Quotations for D-8016Q are prepared per size SKU, and lead time is 30-45 days after sample approval.
- Size SKUs
- D-8016Q-150, D-8016Q-170
- Standard Lead Time
- 30-45 days after sample approval
List the quantity for each D-8016Q size and any other SANIKB models that will ship with it. Private label marking can be raised in the same inquiry; see our OEM and ODM service.
Include these details with the RFQ
- Quantity of D-8016Q-150 and D-8016Q-170
- Destination market and port for D-8016Q
- Deck or wall faucet and waste scope, if any
- Carton marking and label language
- Ship date the D-8016Q order must meet
Treat the lead time as indicative until the D-8016Q quotation is issued.
