Oval Drop-In Bathtub, Wide Flat Flange, 18.5 in High, 58-70 in
SANIKB D-8012Q is an oval drop-in bathtub in white gloss acrylic, 470 mm (18.5 in) high, with a wide flat flange that rests on the surrounding deck. The double-ended, stadium-oval bowl has a centered overflow. Because the wide flange is not drilled for taps, the faucet mounts on the surrounding deck or on the wall. Four sizes are made: D-8012Q-150 at 1485 × 805 × 470 mm (58 × 31.7 × 18.5 in), D-8012Q-155 at 1550 × 795 × 470 mm (61 × 31.3 × 18.5 in), D-8012Q-165 at 1640 × 795 × 470 mm (65 × 31.3 × 18.5 in) and D-8012Q-178 at 1775 × 800 × 470 mm (70 × 31.5 × 18.5 in). All four sizes are cUPC certified, and a written quote follows within 12 business hours.
Compare drop-in shapes in the drop-in bathtubs collection.
More in Drop-In Bathtubs
MOQ per model · one 40HQ container, quantity set by tub size
-
B8022Two-Person Drop-In Whirlpool Bathtub with Twin Headrests, 75 in75" × 55.1" × 29.1"Drop-in (deck or platform)
-
D-8028QCompact Round Drop-In Bathtub, 55 in Diameter55" × 55.1" × 19.3"Drop-in (deck or platform)
-
D-8061QRectangular Drop-In Tub with Wide Flat Flange, 59-71 in59" / 67" / 71" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8051QWide-Rim Double-Ended Drop-In Bathtub, 59 & 67 in59" / 67" × 30.7" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8026QDouble-Ended Rectangular Drop-In Bathtub, 71 in71" × 31.5" × 18.9"Drop-in (deck or platform)
-
D-8021QRectangular Drop-In Bathtub, 29.5 in Wide, 59 & 67 in59" / 67" × 29.5" × 19.3"Drop-in (deck or platform)
-
D-8017QDouble-Ended Drop-In Bathtub with Bowed Ends, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8016QSingle-Ended Rectangular Drop-In Bathtub, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.7"Drop-in (deck or platform)
-
D-8013QRectangular Drop-In Acrylic Bathtub, Narrow Flat Flange, 59-67 in59" / 63" / 67" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8020QRounded Rectangle Double-Ended Drop-In Bathtub, 59-71 in59" / 67" / 71" × 29.5" × 19.3"Drop-in (deck or platform)
-
D-8062QNarrow Oval Drop-In Bathtub with Rolled Flange, 27.6 in Wide, 59 & 67 in59" / 67" × 27.6" × 18.5"Drop-in (deck or platform)
-
D-8022QStadium Drop-In Bathtub, White Gloss Acrylic, Narrow Flange, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8015QOval Drop-In Acrylic Bathtub, Narrow Rounded Flange, 59-67 in59" / 63" / 67" × 31.5" × 19.7"Drop-in (deck or platform)
Tub sheet
Size and installation of D-8012Q
Every option below is a produced configuration with its own SKU. 4 sizes. Name the exact SKU on each purchase order line.
Order codes
| SKU | Size |
|---|---|
| D-8012Q-150 | 58" x 32" |
| D-8012Q-155 | 61" x 31" |
| D-8012Q-165 | 65" x 31" |
| D-8012Q-178 | 70" x 31" |
Mixed-configuration orders are accepted within one purchase order. Confirm the SKU, finish and size on the quotation before sample approval. Request the full configuration list.
Compare · 4 sizes
Size & spec comparison
| 58" x 32"D-8012Q-150 | 61" x 31"D-8012Q-155 | 65" x 31"D-8012Q-165 | 70" x 31"D-8012Q-178 | |
|---|---|---|---|---|
| Overall L×W×D | 58″ × 31.7″ × 18.5″ 1485 × 805 × 470 mm | 61″ × 31.3″ × 18.5″ 1550 × 795 × 470 mm | 65″ × 31.3″ × 18.5″ 1640 × 795 × 470 mm | 70″ × 31.5″ × 18.5″ 1775 × 800 × 470 mm |
Common specs above apply to every size; the table compares only what changes by size. Custom sizes available for OEM/ODM.
Send a spec. Get a real quote in 12 business hours.
Engineer-reviewed. cUPC · CE · ISO 9001 ready. 30–45 day lead time, FOB or CIF.
12 consecutive years at KBIS and IBS.
Standard on every shipment.
Flange & Bowl
Stadium-oval bowl with a wide flat flange
D-8012Q is set into a built deck so that only its wide, flat flange and the bowl show. The bowl is a stadium-oval, double-ended, with a centered overflow.
Wide flange on the deck
The rim is a wide flat flange that bears on the finished deck. Size the deck opening from the approved drawing so the flange overlaps evenly on all sides.
No tap holes in the flange
The flange is not drilled for taps. The faucet mounts on the surrounding deck or on the wall, so fix the supply position before the wall or deck is closed in.
Other flange widths and shapes are in the drop-in bathtub range.
Fit & Footprint
Four lengths from 1485 to 1775 mm
All four sizes are 470 mm (18.5 in) high. Width runs from 795 mm to 805 mm, so the deck depth changes little between sizes.
- D-8012Q-150
- 58" × 31.7" × 18.5" (1485 × 805 × 470 mm)
- D-8012Q-155
- 61" × 31.3" × 18.5" (1550 × 795 × 470 mm)
- D-8012Q-165
- 65" × 31.3" × 18.5" (1640 × 795 × 470 mm)
- D-8012Q-178
- 70" × 31.5" × 18.5" (1775 × 800 × 470 mm)
Drop-in installation needs a deck built to the tub. Take the cut-out size and support details from the approved drawing for the SKU you order, as each length has its own outline.
Plan service access to the waste and overflow into the deck design.
Construction & Finish
White gloss acrylic, wide flange
D-8012Q is made from pure acrylic sheet in white gloss, with a wide flat flange framing the stadium-oval bowl.
White
Gloss across all four sizes
Every D-8012Q size is made in the same white gloss, so a project can mix lengths without a finish mismatch.
Support under the shell is confirmed on the approved drawing, so settle the base arrangement before the deck is framed.
The wide flange is exposed during handling. Agree edge protection in packing and a damage reporting window before shipment.
Check flange edges when cartons are opened and record any damage before the tub is moved.
Compliance
cUPC certification: D-8012Q
Documents are requested against D-8012Q. List the SKUs on the order so the paperwork matches the delivery.
D-8012Q is cUPC certified in all four sizes. For a submittal, request the current certificate number and its validity for the destination market.
Give your market and document list in the inquiry, and written replies come within 12 business hours.
Procurement
Ordering D-8012Q by length
D-8012Q has four SKUs: D-8012Q-150, D-8012Q-155, D-8012Q-165 and D-8012Q-178.
- Standard Lead Time
- 30-45 days after sample approval
- Sizes
- 4 lengths, 1485 to 1775 mm
Quantities for each length are confirmed at quotation. Other SANIKB models for the same project are in the bathtub manufacturer range.
Include these details with the RFQ
- Quantity for D-8012Q-150, D-8012Q-155, D-8012Q-165 and D-8012Q-178
- Destination market and port
- Deck cut-out drawing request
- Faucet position: surrounding deck or wall
- Carton marking
- Target delivery window
The D-8012Q lead time is indicative until the quotation confirms it.
