Double-Ended Drop-In Bathtub with Bowed Ends, 59 & 67 in
SANIKB D-8017Q is a double-ended acrylic drop-in bathtub with straight long sides and short ends that bow outward. The flat flange runs slim along the sides and widens at both ends. It is made as D-8017Q-150 at 1500 x 750 x 490 mm (59 x 29.5 x 19.3 in) and D-8017Q-170 at 1700 x 800 x 490 mm (67 x 31.5 x 19.3 in).
The shell is glossy white and cUPC certified. The flange has no tap holes: the faucet mounts on the surrounding deck or on the wall, so neither curved end is given over to fittings. More shells are in the drop-in bathtubs collection.
More in Drop-In Bathtubs
MOQ per model · one 40HQ container, quantity set by tub size
-
B8022Two-Person Drop-In Whirlpool Bathtub with Twin Headrests, 75 in75" × 55.1" × 29.1"Drop-in (deck or platform)
-
D-8028QCompact Round Drop-In Bathtub, 55 in Diameter55" × 55.1" × 19.3"Drop-in (deck or platform)
-
D-8061QRectangular Drop-In Tub with Wide Flat Flange, 59-71 in59" / 67" / 71" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8051QWide-Rim Double-Ended Drop-In Bathtub, 59 & 67 in59" / 67" × 30.7" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8026QDouble-Ended Rectangular Drop-In Bathtub, 71 in71" × 31.5" × 18.9"Drop-in (deck or platform)
-
D-8021QRectangular Drop-In Bathtub, 29.5 in Wide, 59 & 67 in59" / 67" × 29.5" × 19.3"Drop-in (deck or platform)
-
D-8016QSingle-Ended Rectangular Drop-In Bathtub, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.7"Drop-in (deck or platform)
-
D-8013QRectangular Drop-In Acrylic Bathtub, Narrow Flat Flange, 59-67 in59" / 63" / 67" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8020QRounded Rectangle Double-Ended Drop-In Bathtub, 59-71 in59" / 67" / 71" × 29.5" × 19.3"Drop-in (deck or platform)
-
D-8062QNarrow Oval Drop-In Bathtub with Rolled Flange, 27.6 in Wide, 59 & 67 in59" / 67" × 27.6" × 18.5"Drop-in (deck or platform)
-
D-8022QStadium Drop-In Bathtub, White Gloss Acrylic, Narrow Flange, 59 & 67 in59" / 67" × 29.5" / 31.5" × 19.3"Drop-in (deck or platform)
-
D-8015QOval Drop-In Acrylic Bathtub, Narrow Rounded Flange, 59-67 in59" / 63" / 67" × 31.5" × 19.7"Drop-in (deck or platform)
-
D-8012QOval Drop-In Bathtub, Wide Flat Flange, 18.5 in High, 58-70 in58" / 61" / 65" / 70" × 31.3" / 31.5" / 31.7" × 18.5"Drop-in (deck or platform)
Tub sheet
Size and installation of D-8017Q
Every option below is a produced configuration with its own SKU. 2 sizes. Name the exact SKU on each purchase order line.
Order codes
| SKU | Size |
|---|---|
| D-8017Q-150 | 59" x 30" |
| D-8017Q-170 | 67" x 31" |
Mixed-configuration orders are accepted within one purchase order. Confirm the SKU, finish and size on the quotation before sample approval. Request the full configuration list.
Compare · 2 sizes
Size & spec comparison
| 59" x 30"D-8017Q-150 | 67" x 31"D-8017Q-170 | |
|---|---|---|
| Overall L×W×D | 59″ × 29.5″ × 19.3″ 1500 × 750 × 490 mm | 67″ × 31.5″ × 19.3″ 1700 × 800 × 490 mm |
Common specs above apply to every size; the table compares only what changes by size. Custom sizes available for OEM/ODM.
Send a spec. Get a real quote in 12 business hours.
Engineer-reviewed. cUPC · CE · ISO 9001 ready. 30–45 day lead time, FOB or CIF.
12 consecutive years at KBIS and IBS.
Standard on every shipment.
Shape & Backrest
Bowed ends with a backrest at each end
D-8017Q is rectangular in plan, but its short ends curve outward instead of meeting the long sides at square corners. Both ends are shaped as backrests.
Recline at either end
With a backrest at both ends, D-8017Q does not fix a bather end. The faucet can follow the supply position on the surrounding deck or wall instead of deciding which way the bather faces.
Flange widens at the curved ends
The flat flange runs slim along the long sides and broadens where the ends bow out. It has no tap holes, so the whole border stays clear.
Other double-ended outlines, including rounded-rectangle and oval shells, are in the drop-in range.
Fit & Platform
Two sizes at 490 mm high
D-8017Q-150 is 59 x 29.5 x 19.3 inches (1500 x 750 x 490 mm). D-8017Q-170 is 67 x 31.5 x 19.3 inches (1700 x 800 x 490 mm), 200 mm longer and 50 mm wider.
- D-8017Q-150
- 59" x 29.5" x 19.3" (1500 x 750 x 490 mm)
- D-8017Q-170
- 67" x 31.5" x 19.3" (1700 x 800 x 490 mm)
- Rim
- Slim flat flange, wider at both ends
- Faucet Mounting
- Surrounding deck or wall; no tap holes in the flange
Because the ends bow outward, the platform opening for D-8017Q may not be a plain rectangle. Take its outline from the approved drawing instead of cutting to the overall length and width.
Mark the wider end flanges on the platform setting-out so any deck faucet holes clear them.
Construction & Finish
Glossy white acrylic
The D-8017Q shell is made from pure acrylic sheet and finished in glossy white.
White
Same finish in both lengths
D-8017Q-150 and D-8017Q-170 share the glossy white finish, so shorter and longer bathrooms in one project can take matching tubs.
Protect the glossy D-8017Q surface while the surrounding platform is tiled, and check it again at handover.
Agree how surface damage found on arrival is recorded and reported for D-8017Q.
Compliance
cUPC certified in both sizes
Ask for D-8017Q paperwork by model and size SKU so each document matches the tub delivered.
Both D-8017Q sizes are cUPC certified. Request the certificate number and its validity date before the tub is added to a submittal package.
If the destination market needs other documents, name them in the inquiry so they are settled at quotation; replies come within 12 business hours.
Procurement
Quoting D-8017Q
Each D-8017Q size is quoted as its own SKU, and lead time is 30-45 days after sample approval.
- Size SKUs
- D-8017Q-150, D-8017Q-170
- Standard Lead Time
- 30-45 days after sample approval
Where D-8017Q ships with other SANIKB models, put the whole list in one inquiry so the quotation shows quantities per model.
Include these details with the RFQ
- D-8017Q-150 and D-8017Q-170 quantities
- Destination market and port for this order
- Whether a deck or wall faucet is needed alongside D-8017Q
- Carton marking and any private label
- Target date for the D-8017Q shipment
The lead time stays indicative until the D-8017Q quotation is issued.
